Bơm ly tâm => Bơm ly tâm Ebara CDA

Bơm ly tâm Ebara CDA

Xuất xứ: ITALY

Giá : Liên hệ


MÔ TẢ CHI TIẾT SẢN PHẨM



Bơm ly tâm 2 tầng cánh Ebara CDA có cấu tạo thân và buồng bơm bằng gang đúc, cánh bơm đồng, thiết kế gọn nhẹ. Ứng dụng nhiều trong bơm tăng áp, bơm cần nhiều lưu lượng cho nhà máy, công trình, dự án, khu chung cư...

Nội dung

Thông số

Sản phẩm

Bơm ly tâm 2 tầng cánh Ebara CDA

Hãng sản xuất

Ebara

Loại

Bơm ly tâm 2 tầng cánh

Công suất (Kw)

0.75 - 4

Lưu lượng max (lít / phút)

210

Cột áp max  (m)

60.4

Đường kính ống hút (mm)

32, 40

Đường kính ống xả (mm)

25

Nhiệt độ chất lỏng

60oC

Nguồn điện sử dụng

220V, 380V – 50Hz

Ứng dụng trong

Bơm tưới tiêu, rửa lọc, tăng áp

Cánh bơm

Inox 304

Cấp độ bảo vệ

IP55

Con dấu cơ khí

Carbon / Ceramic / NBR

Lớp cách nhiệt

F(155oc)

Thân bơm, buồng bơm, động cơ

Inox 304

Áp lực

8 Bar
