Bơm ly tâm => Bơm ly tâm Ebara CD

Bơm ly tâm Ebara CD

Xuất xứ: ITALY

Giá : Liên hệ


MÔ TẢ CHI TIẾT SẢN PHẨM



Bơm ly tâm 1 tầng cánh Ebara CD được kết cấu toàn bộ bằng Inox 304, có buồng xoắn tích hợp được bởi quy trình dập thủy lực, vận hành ít tiếng ồn, kích thước gọn nhẹ. Ứng dụng trong vận chuyển nước nóng lạnh, hệ thống bơm tăng áp, tưới tiêu, rửa lọc....

Nội dung

Thông số

Sản phẩm

Bơm ly tâm 1 tầng cánh Ebara CD

Hãng sản xuất

Ebara

Loại

Bơm ly tâm 1 tầng cánh

Công suất (Kw)

0.37 - 1.5

Lưu lượng max (lít / phút)

250

Cột áp max  (m)

31

Đường kính ống hút (mm)

32, 40

Đường kính ống xả (mm)

25

Nhiệt độ chất lỏng

90oC

Nguồn điện sử dụng

220V, 380V – 50Hz

Ứng dụng trong

Bơm tưới tiêu, rửa lọc, tăng áp

Cánh bơm

Inox 304

Cấp độ bảo vệ

IP55

Con dấu cơ khí

Carbon / Ceramic / NBR

Lớp cách nhiệt

F(155oc)

Thân bơm, buồng bơm, động cơ

Inox 304

Áp lực

8 Bar
